Ghost Code: Uncovering Hidden Execution on the MediaTek MT7697

---

Connecting via SWD

I used the Black Magic Probe to connect directly to the MT7697's SWD interface. The connection worked flawlessly — I could halt, step, and inspect registers in GDB:

(gdb) info reg
r0   0x2001417c
r1   0x102ffb8a
r2   0x2a8
r3   0x8
...
sp   0x20014148
lr   0x102721
pc   0x102686
xpsr 0x01000000

Registers updated exactly as expected when single-stepping through code.

---

The Ghost Code Phenomenon

The confusion started when trying to disassemble memory. Every instruction appeared as a movs r0, r0 no-op, and memory reads returned only 0x00000000.

(gdb) x/16i $pc
0x102682: movs r0, r0
0x102684: movs r0, r0
0x102686: movs r0, r0
...

Even worse, dumping flash or SRAM while the device was running showed only zeros:

(gdb) x/16xw 0x10000000
0x10000000: 0x00000000 0x00000000 0x00000000 0x00000000

Yet clearly, real code was executing. This paradox is what I call ghost code execution.

---

Breakpoints That Never Land

Setting both software and hardware breakpoints failed. The debugger would accept the command, but execution never stopped at the desired address. This suggested that code fetches were happening outside of the regions GDB could see, or that the SoC was actively blocking debug patching.

Why Breakpoints Fail

On ARM Cortex-M devices, breakpoints are typically set either by patching instructions in flash or by using the Flash Patch and Breakpoint (FPB) unit. But with the MT7697:

• Flash reads always return 0x00, so GDB cannot patch instructions
• Execute-only filtering prevents the debugger from verifying code locations
• Result: breakpoints are silently ignored, confirming the bus-level security filter at work

The FPB unit relies on being able to compare actual instruction addresses with breakpoint locations. Since the debugger can't read the real instructions due to the SFC filtering, it can't properly configure hardware breakpoints either.

---

Relocated Vector Table

When inspecting the System Control Block (SCB) registers, I found the vector table had been relocated into SRAM at 0x20000000:

(gdb) x/1wx 0xE000ED08
0xe000ed08: 0x20000000   # VTOR

This meant execution was jumping into RAM very early, instead of staying in flash.

Using the ELF we dumped offline, I cross-referenced where the vector table and reset handler were originally located. This confirmed that the firmware copies itself into RAM during startup, then runs from there — with protections applied.

---

Registers vs Memory Access

Here’s the strangest part: CPU registers and system control space were fully readable, but memory-mapped flash and RAM were blocked:

(gdb) x/1wx 0xE000ED00    # CPUID
0xe000ed00: 0x410fc241    # ARM Cortex-M4

(gdb) x/1wx 0x10000000    # Flash
0x10000000: 0x00000000    # Always zero

The ARM debug interface (AHB-AP) could access the SCB, NVIC, and debug control blocks — but anything resembling firmware memory was filtered out.

---

What We Learned

1. MediaTek bypasses ARM's MPU

On Cortex-M4 cores, the Memory Protection Unit (MPU) is configured through registers in the System Control Block (SCB), starting at 0xE000ED90. Here's what each register does, and how to interpret the values we observed on the MT7697:

• MPU_TYPE = 0x00000800 → 8 regions supported
• MPU_CTRL = 0x0 → MPU disabled

2. Custom bus-level security

The Serial Flash Controller (SFC) and bus fabric enforce execute-only memory access, bypassing ARM's standard protection mechanisms.

3. eFUSE-controlled at boot

The MT7697’s protection isn’t software-driven — it’s baked into the silicon.
On reset, the Boot ROM reads configuration bits from eFUSE. These one-time programmable values permanently control security features such as the Serial Flash Controller (SFC) execute-only mode. By the time user code ever runs, the ROM has already enabled filtering logic that:

• Allows instruction fetches from flash,
• Blocks data or debug reads (returning zeros),
• Prevents breakpoints or disassembly from working in protected regions.

This explains why, under normal debugging conditions, everything looks blank:

• Registers: Always visible (PC, SP, LR, GPRs).
• System Control Block (SCB): Blocked — attempts to read 0xE000ED00 and neighbors fail.
• Memory (flash, SRAM): Reads return 0x00000000.
• Disassembly: Only movs r0, r0, since 0x00 0x00 decodes to that instruction.

In this state, the only reliable information is the live CPU registers; all memory and system context is hidden.

---

4. Boot window investigation

Initially, I hypothesized that catching the CPU before the Boot ROM finished applying eFUSE settings might reveal a vulnerable window where protections weren't yet active. To test this theory, I wrote scripts that rapidly cycled reset and attach attempts:

import gdb, time

class MT7697BootAttack:
  def attempt_connection(self):
      try:
          gdb.execute("target extended-remote \\.\COM25")
          gdb.execute("monitor reset")
          gdb.execute("monitor swdp_scan")
          gdb.execute("attach 1")
          gdb.execute("monitor halt")
          # Test SCB and eFUSE access
          cpuid = gdb.execute("x/1wx 0xE000ED00", to_string=True)
          efuse = gdb.execute("x/1wx 0x81070000", to_string=True)
          print(f"CPUID: {cpuid}, eFUSE: {efuse}")
      except gdb.error:
          print("Attach failed, retrying...")

attack = MT7697BootAttack()
for i in range(100):
  attack.attempt_connection()
  time.sleep(0.05)

This approach successfully caught the system at different execution points, evidenced by varying PC values across attempts. More importantly, it revealed that the System Control Block (SCB) was consistently accessible:

• CPUID = 0x410fc241 → confirmed Cortex-M4
• VTOR = 0x20000000 → vector table relocated into SRAM
• AIRCR = 0xFA050000 → reset/security configuration visible
• MPU_TYPE = 0x00000800 → 8 regions supported
• MPU_CTRL = 0x0 → MPU disabled

However, eFUSE registers remained completely inaccessible throughout all timing attempts:

(gdb) x/1wx 0x81070000    # eFUSE EE_CTRL
0x81070000: 0x00000000    # Always zero

(gdb) x/1wx 0x81070030    # eFUSE RDATA0
0x81070030: 0x00000000    # Always zero

Key Discovery: Two-Tier Protection

The boot window experiments revealed that MediaTek implements two separate protection mechanisms:

1. ARM SCB protection - Temporarily disabled during reset/debug attachment, allowing normal CPU debugging
2. eFUSE hardware protection - Permanent silicon-level security that activates immediately upon power-on and cannot be bypassed with timing attacks

This explains why we could successfully read ARM standard registers (proving we were catching genuine boot states) while eFUSE registers remained perpetually protected. The eFUSE controller has dedicated hardware security that operates independently of the ARM core's debug architecture.

Attack Verdict

The timing-based boot window attack does not work against MediaTek's eFUSE implementation. Unlike some other SoCs where eFUSE protection is software-initialized and vulnerable to precise timing, the MT7697's eFUSE security is hardware-enforced from power-on and immune to debugger timing manipulation.

MediaTek's security implementation demonstrates sophisticated defense-in-depth, with eFUSE protection operating at a level below even the ARM debug subsystem.

---

5. eFUSE & Security Registers

Digging into the MT7697 SDK revealed the exact registers that the Boot ROM initializes from eFUSE to enforce these protections:

#define SFC_SECURITY_REG   (CM4_SFC_BASE + 0x8008)
#define SFC_CONTROL_REG    (CM4_SFC_BASE + 0x800C)
#define SFC_CRC_REG        (CM4_SFC_BASE + 0x803C)

These Serial Flash Controller (SFC) registers control the execute-only memory access behavior:

• SFC_SECURITY_REG - Configures memory protection modes and access restrictions
• SFC_CONTROL_REG - Controls the SFC operation and filtering behavior
• SFC_CRC_REG - Validates firmware integrity during the boot process

The Boot ROM reads one-time programmable eFUSE values and uses them to lock these registers into their security configuration. Once set, they cannot be reconfigured by user code - explaining why attempts to manually disable the protection during runtime failed completely.

This hardware-enforced security model moves the protection layer below the ARM core itself, making it invisible to standard debugging tools that operate at the CPU level.

---

Conclusion

The MT7697 doesn’t just rely on ARM’s built-in features. MediaTek added a custom layer of protection that makes firmware invisible to debuggers while still executing normally. This “ghost code” behavior is a powerful anti-reversing measure, and it shows how IoT security is moving deeper into silicon.

For researchers, the lesson is clear: even when memory looks blank, the CPU may be running a hidden world of code just beneath your probe.
